Product Code : ARI-09
Brand Name : AMERICAN RUBBER INDUSTRIES
Price And Quantity
  • Minimum Order Quantity
  • As per the Product Piece
Product Description

Hot Water Hose

Supported by in-house quality test department & modern manufacturing unit, we are noted as the reckoned manufacturer and exporter of Hot Water Hose. Manufactured by our well-trained professional using high-end quality materials, these hoses are available in different sizes & thicknesses. Suitable for conveying hot water at a pressure of up to 0.7 MPa and at a temperature below 100ºC, this Hot Water Hose is highly demanded in steel mills, locomotive industry, power stations and chemical & fertilizer industries

Features:

  • High grade finish
  • Hot water resistant
  • High durability

Further Details:

Construction:

Lining

:

Smooth lining of suitable rubber compounds, uniform in thickness, resistant to the hot water.

Reinforcement

:

Plies of rubber impregnated woven textile or braided of high strength natural or synthetic fibre.

Cover

:

Smooth, fluted or cloth marked finish of suitable rubber compound of good weather resistant to abrasion, tear and heat.

Pressures: W.P. of 0.7 MPa & min. B.P. of 2.2 MPa.

Nom Bore in {mm}

Tolerance on Nom.bore

(mm)

Min .Thk. Of lining (mm)

Min .Thk. Of cover (mm)

Woven Textile

Woven Textile

Out side dia

(mm)

No .of piles

Outside dia.

(mm)

No . Of plies

10.00

± 0.75

1.5

1.0

16.5

2

15.5

1

12.50

± 0.75

1.5

1.0

19.0

2

18.0

1

16.00

± 0.75

1.5

1.0

22.5

2

21.5

1

20.00

±0.75

1.5

1.0

27.0

3

25.0

1

25.00

± 1.25

2.0

1.0

33.5

4

34.0

2

31.50

± 1.25

2.0

1.0

40.5

4

41.0

2

38.00

± 1.25

2.0

1.0

48.5

5

47.5

2

45.00

± 1.50

2.5

1.0

56.5

5

57.5

3

50.00

± 1.50

2.5

1.0

61.5

5

62.5

3

56.00

± 1.50

2.5

1.0

67.5

5

67.5

3

63.00

± 1.50

2.5

1.0

76.5

6

75.5

3

  •  W.P. :Working Pressure, P.P. : Proof Pressure, B.P. : Burst Pressure, 1MPa : 10.2Kgf/Cm2 1Kgf/Cm2 :100KN/m2
  • Length : Mandrel made hose upto 20 mtr., Moulded braided hose in continuos long length.
