Agriculture Spray Hose

Name: Agriculture Spray Hose
Brand: AMERICAN RUBBER INDUSTRIES
Price: 100 INR
Availability: InStock

Price 100 INR/ Piece

Get a Price/Quote

MOQ : 100 Pieces

Agriculture Spray Hose Specification

Length
Available in 50 m and 100 m coils

Color
Yellow with red or blue strip

Diameter
Inner diameter: 8.5 mm to 12 mm; Outer diameter: 14 mm to 19 mm

Feature
Lightweight, kink-resistant, flexible, weather-resistant, UV protected

Temperature Resistance
-10C to +60C

Width
Varies as per size, typically around 15-20 mm

Usage & Applications
Agricultural spraying, pesticide and herbicide application, irrigation, and general farming use

Tensile Strength
High tensile strength, designed for pressure resistance

Style
Flexible, corrugated

Hardness
Medium, suitable for repeated bending

Thickness
2.5 mm to 4.0 mm

Water Absorption
Negligible

Resistance level
Good resistance to chemicals and abrasion

Natural Rubber
Not Applicable (Made from PVC synthetic polymer)

Thermal Conductivity
Low

Components
Flexible PVC construction, reinforced with multi-layer yarn

Weight
Approx. 7-15 kg per 100 m coil depending on size

Flame Resistance Level
Non-flammable / Standard

Tolerance
+/- 0.2 mm

Part Type
Hose

Surface Finish
Glossy and ribbed outer surface

Material
PVC (Polyvinyl Chloride)

Product Type
Agriculture Spray Hose

Density
0.05 Gram per cubic centimeter(g/cm3)

Rubber Type
PVC Synthetic Polymer

Size
8.5 mm, 10 mm, 12 mm (Inner Diameter)

Bursting Pressure
Approx. 20-40 bar depending on size

Inner Tube Color
Yellow

Minimum Bend Radius
40 mm

Life Span
3-5 years in field conditions

Manufacturing Type
Extruded with multi-layer braided design

Crack Resistance
High, tested for continuous outdoor exposure

Working Pressure
10-25 bar

Flexibility
Highly flexible, easy handling

Environmental Compliance
Lead-free, RoHS compliant

Odor
Odorless

Reinforcement
High tensile synthetic yarn

UV Resistance
Excellent, suitable for outdoor use

Packing Type
Shrink-wrapped in coils

Agriculture Spray Hose Trade Information

Minimum Order Quantity
100 Pieces

Supply Ability
1000 Pieces Per Day

Delivery Time
1 Week

Sample Available
Yes

Sample Policy
Free samples are available

Packaging Details
Customized packing

Main Domestic Market
All India

About Agriculture Spray Hose

Agriculture Spray Hose

Backed by world class infrastructure base & large shipping network, we are considered as the pioneer manufacturer and exporter of Agriculture Spray Hose. These spray hoses are made by our well talented manpower using high-end quality materials. Ideal for spraying pesticides, these hoses are widely used in agriculture industries. Before the final dispatch, our Agriculture Spray Hose is rigorously inspected by our expert quality analyzers on certain quality parameters.

Features:

Flexibility
Leakage proof
High quality

Further Details:

Application: For carrying power cables in glass works, electrical furnaces, servicing in iron & steel industries for protection from exposure to high temperature, current leakage, radiation from steel furnace, open flame and splashes of hot metal.

Construction:

Lining	:	Smooth, non conductive, natural/ synthetic/blend rubber compound.
Reinforcement	:	Natural/synthetic rubberized woven textile fabric.
Cover	:	Oil, heat and electrical resistant synthetic rubber compound with or without asbestos outer.

Nom. Bore in (mm)	Tolerance on Nom. bore (mm)	W.P. ( Kg. / cm2 )	P.P. ( Kg. / cm2 )	B.P. ( Kg. / cm2 )
12.5	± 0.75	10.0	20.0	40.0
16.0	± 0.75	10.0	20.0	40.0
20.0	± 0.75	10.0	20.0	40.0
25.0	± 1.25	10.0	20.0	40.0
28.0	± 1.25	10.0	20.0	40.0
31.5	± 1.25	10.0	20.0	40.0
35.0	± 1.50	10.0	20.0	40.0
38.0	± 1.50	10.0	20.0	40.0
50.0	± 2.00	10.0	20.0	40.0
56.0	± 2.00	10.0	20.0	40.0
60.0	± 2.00	10.0	20.0	40.0
63.0	± 2.00	10.0	20.0	40.0
70.0	± 2.00	10.0	20.0	40.0
75.0	± 2.00	10.0	20.0	40.0
100.0	± 2.50	10.0	20.0	40.0
150.0	± 3.00	10.0	20.0	40.0

W.P. :Working Pressure, P.P. : Proof Pressure, B.P. : Burst Pressure, 1MPa : 10.2Kgf/Cm2 1Kgf/Cm2 :100KN/m2
Length : Mandrel made hose upto 20 mtr., Moulded braided hose in continuos long length.

Superior Durability and Performance

Engineered with high tensile synthetic yarn reinforcement and a multi-layer extruded design, this hose excels under demanding agricultural conditions. Its excellent crack and UV resistance enable it to perform reliably for 3-5 years in field environments. The hose withstands working pressures up to 25 bar and bursting pressures up to 40 bar, making it a safe and robust choice for routine and intensive spraying tasks.

Flexible and Easy to Handle

Highly flexible construction allows for effortless handling, even around tight corners and obstacles. With a minimum bend radius of 40 mm and medium hardness, the hose is well-suited for repeated bending and repositioning during agricultural applications. Its lightweight and kink-resistant features facilitate efficient use and transport across fields.

Eco-Friendly and Safe

Manufactured with lead-free materials and compliant with RoHS standards, the hose ensures safe application in environments requiring environmental responsibility. The odorless composition and negligible water absorption further guarantee user comfort and hygiene during prolonged outdoor usage.

FAQs of Agriculture Spray Hose:

Q: How do I use the agriculture spray hose for pesticide and herbicide applications?

A: Connect the hose to compatible spray equipment and secure the fittings. Its flexible design allows smooth maneuvering around crops and obstacles, enabling precise chemical delivery during agricultural spraying.

Q: What is the typical lifespan of this hose in outdoor farming conditions?

A: When used under recommended pressure and temperature conditions, the hose generally lasts between 3 to 5 years, even with continuous outdoor exposure, thanks to its crack-resistant and UV-protected construction.

Q: When should I consider replacing the spray hose?

A: Replace the hose if you notice significant wear, visible cracks, or reduced flexibility, especially if it approaches the end of its 35 year lifespan or after exposure to extreme pressures beyond its rated limits.

Q: Where can this hose be effectively applied on my farm?

A: The hose is suitable for a variety of applications, including crop spraying, irrigation, pesticide and herbicide application, and other general farming tasks requiring high flexibility and chemical resistance.

Q: What benefits does the yellow color with red or blue strip offer?

A: This color scheme enhances visibility in fields, reducing the risk of tripping and making the hose easy to locate, especially in dense agricultural areas.

Q: How is the hose constructed to ensure pressure resistance and durability?

A: The hose features multi-layer extrusion reinforced with high tensile synthetic yarn, ensuring high strength and resistance to bursting pressures up to 40 bar and working pressures up to 25 bar.

Q: What makes this hose environmentally safe and compliant?

A: Manufactured entirely from PVC synthetic polymer that is lead-free and RoHS compliant, it meets environmental standards and is safe for long-term use in agricultural settings.
